The Safety Canopy

system, in combination with safety belts, can help

reduce the risk of severe injuries in the event of a significant side impact
collision or rollover event.

Children 12 years old and under should always be properly restrained in
the second row seats. The Safety Canopy

will not interfere with

children restrained using a properly installed child or booster seat
because it is designed to inflate downward from the headliner above the
doors along the side window opening.

The Safety Canopy

system is designed to activate when the vehicle

sustains lateral deceleration sufficient to cause the side crash sensor to
close an electrical circuit that initiates Safety Canopy

inflation or when

a certain likelihood of a rollover event is detected by the rollover sensor.

The Safety Canopy

is mounted to roof side-rail sheet metal, behind the

headliner, along the entire side of the vehicle. In certain lateral collisions
or rollover events, the Safety Canopy

system will be activated,

regardless of which seats are occupied. The Safety Canopy

is designed

to inflate between the side window area and occupants to further
enhance protection provided in side impact collisions and rollover events.

The fact that the Safety Canopy

did not activate in a collision does not

mean that something is wrong with the system. Rather, it means the
forces were not of the type sufficient to cause activation. The Safety
Canopy

is designed to inflate in certain side impact collisions or

rollover events, not in rear impact, frontal or near-frontal collisions,
unless the collision causes sufficient lateral deceleration or rollover
likelihood.

Several Safety Canopy

system components get hot after

inflation. Do not touch them after inflation.
