If two previously programmed coded keys are not available, you must
take your vehicle to your authorized dealer to have the spare key(s)
programmed.

Please read and understand the
entire procedure before you begin.

1. Insert the first previously
programmed

coded key

into the

ignition.

2. Turn the ignition from the 1 (LOCK) position to the 3 (RUN) position.
Keep the ignition in the 3 (RUN) position for at least three seconds, but
no more than 10 seconds.

3. Turn the ignition to the 1 (LOCK) position and remove the first

coded

key

from the ignition.

4. Within ten seconds of turning the ignition to the 1 (LOCK) position,
insert the second previously

coded key

into the ignition.

5. Turn the ignition from the 1 (LOCK) position to the 3 (RUN) position.
Keep the ignition in the 3 (RUN) position for at least three seconds, but
no more than 10 seconds.

6. Turn the ignition to the 1 (LOCK) position and remove the second
previously programmed

coded key

from the ignition.

7. Within twenty seconds of turning the ignition to the 1 (LOCK)
position and removing the previously programmed

coded key,

insert the

new unprogrammed key (new key/valet key) into the ignition.

8. Turn the ignition from the 1 (LOCK) position to the 3 (RUN) position.
Keep the ignition in the 3 (RUN) position for at least three seconds but
not more than 10 seconds.

9. Remove the newly programmed

coded key

from the ignition.

If the key has been successfully programmed it will start the vehicle’s
engine and the theft indicator light will illuminate for three seconds and
then go out.

If the key was not successfully programmed, it will not start your
vehicle’s engine and the theft indicator light will flash on and off. Wait 20
seconds and you may repeat Steps 1 through 8. If failure repeats, bring
your vehicle to your authorized dealer to have the new key(s)
programmed.

To program additional new unprogrammed key(s), wait twenty seconds
and then repeat this procedure from Step 1.

2006 Five Hundred

(500)

Owners Guide (post-2002-fmt)
USA

(fus)

Locks and Security

98
