Fuel gauge:

Indicates

approximately how much fuel is left
in the fuel tank (when the ignition
is in the ON position). The fuel
gauge may vary slightly when the
vehicle is in motion or on a grade.

The FUEL icon and arrow indicates
which side of the vehicle the fuel
filler door is located.

Refer to

Filling the tank

in the

Maintenance and Specifications

chapter for more information.

Tachometer:

Indicates the engine

speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale may damage the engine.

Odometer:

Registers the total miles (kilometers) of the vehicle.

Without Message Center

With Message Center

Refer to

Message Center

in the

Driver Controls

chapter on how to

switch the display from Metric to
English.

Trip odometer:

Registers the miles (kilometers) of individual journeys.

Without Message Center

To reset, tap on the ODO/TRIP
button to toggle the display between
the trip and the odometer. Holding
the ODO/TRIP button for two
seconds or more will reset the trip
odometer to zero.

2006 Five Hundred

(500)

Owners Guide (post-2002-fmt)
USA

(fus)

Instrument Cluster

15
