background image

With Message Center

To reset with the ODO/TRIP button:

Tap on the button to toggle the display between the trip and the
odometer. Holding the ODO/TRIP button for two seconds or more will
reset the trip odometer to zero.

To reset with the message center
buttons:

Select the TRIP function from the
INFO menu. Depressing the
RESET control for approximately
one second will reset the trip
odometer to zero.

Note:

The following is for vehicles without a message center. For

vehicles with a message center, refer to

Message Center

in the

Driver

Controls

chapter.

Oil Life/Oil Change:

OIL LIFE

displayed when the engine oil life
remaining is 10 percent and again
when the engine oil life remaining is
between 5% and 1%. When oil life
left reaches 0%, the OIL CHANGE message will be displayed. An oil
change is required whenever indicated by the display and according to
the recommended maintenance schedule. USE ONLY RECOMMENDED
ENGINE OILS.

To reset the oil monitoring system to 100% after each oil change
[approximately 5,000 miles (8,000 km) or 180 days] perform the
following:

1. Tap on the ODO/TRIP button to toggle the display between the
odometer and trip odometer.

2. Tap on the ODO/TRIP button again to toggle the display between the
trip odometer and OIL LIFE XX% display.

3. Press and hold the ODO/TRIP button for ten seconds or more to
display OIL LIFE 100%. Your oil life is now reset.

4. Tap on the ODO/TRIP button to return the display to odometer.

2006 Five Hundred

(500)

Owners Guide (post-2002-fmt)
USA

(fus)

Instrument Cluster

16
