PRINCIPLE OF OPERATION

The traction control system helps avoid
drive wheel spin and loss of traction.

If your vehicle begins to slide, the system
applies the brakes to individual wheels
and, when needed, reduces engine power
at the same time. If the wheels spin when
accelerating on slippery or loose surfaces,
the system reduces engine power in order
to increase traction.

USING TRACTION CONTROL

In certain situations, for example stuck in
snow or mud, it may be beneficial for you
to switch the traction control system off.
This allows the wheels to spin with full
engine power.

Note:

A MyKey can be set up to prevent the

MyKey user from switching the traction
control system off.  See

MyKey™

 (page

46).

E179110

Press the traction control button located
on the instrument panel. It illuminates
when you switch the system off.

AdvanceTrac with RSC Features

Traction

control system

Electronic

stability

control

Roll stability

control

Electronic

stability

control off

warning lamp

Button func-

tions

Enabled

Enabled

Enabled

Illuminated
during bulb
check

Default at
engine start-up

Disabled

1

Enabled

Enabled

Illuminated

Button pressed
momentarily

Enabled

Enabled

Enabled

Not illuminated

Button pressed
again after
deactivation

1

Engine traction control and two-wheel spin brake traction control functions are disabled.

Single-wheel spin traction control is always enabled.
