Rear View Camera- Page 146

E130178

Rear detection zone: Up to 72 in
(183 cm) from the rear bumper.

A

Note:

Accessories that block the detection

zone of the system may create false alerts.

Note:

Keep the sensors free from snow, ice

and large accumulations of dirt.

Note:

If your vehicle sustains damage

leaving the sensors misaligned, this will
cause inaccurate measurements or false
alerts.

A tone will sound in the following manner
when objects are near the rear bumper:
•

Objects detected by the rear sensors
produce a low-pitched tone.

•

An alert will only sound for three
seconds if an object is further than 10 in
(25 cm) from the side of your vehicle.

The system detects objects when you shift
into reverse (R) and:
•

Your vehicle is moving toward a
stationary object at a speed of 3 mph
(5 km/h) or less.

•

Your vehicle is stationary but an object
is approaching your vehicle at a speed
of 3 mph (5 km/h) or less.

•

Your vehicle is moving at a speed of
3 mph (5 km/h) or less, and an object
is approaching your vehicle at a speed
of 3 mph (5 km/h) or less.

Note:

The rate of the tone increases as your

vehicle moves closer to an object.

When the parking aid system sounds a
tone, the audio system may reduce the set
volume.  When the warning ends, the audio
system returns to the previously set
volume.

Note:

Volume reduction is not a standard

feature of all audio systems.

Switching the Parking Aid System
Off

E177143

Press the button to switch the system off.
The system remains off until you switch
the ignition off. The button is located on
the instrument panel.

REAR VIEW CAMERA

WARNINGS

Objects in the display are closer than
they appear.

143

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Parking Aids

 (If Equipped)
