Select to distribute air through
the windshield air vents. You can
also use this setting to defog or

clear the windshield of a thin covering of
ice. You can also increase the temperature
and fan speed to improve clearing.

HINTS ON CONTROLLING THE
INTERIOR CLIMATE

General Hints

Note:

Prolonged use of recirculated air may

cause the windows to fog up.

Note:

A small amount of air may be felt

from the footwell air vents regardless of the
air distribution setting.

Note:

To reduce humidity build-up inside

your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note:

Do not place objects under the front

seats as this may interfere with the airflow
to the rear seats.

Note:

Keep the air intakes in front of the

windshield free from obstruction (such as
snow or leaves) to allow the climate control
system to function effectively.

Note:

To reduce fogging of the windshield

during humid weather, adjust the air
distribution control to the windshield air
vents position. Increase the temperature
and fan speed and press the A/C button to
improve clearing, if required.

Heating the Interior Quickly

Adjust the fan speed to the highest
speed setting.

Adjust the temperature control to the
highest setting.

Adjust the air distribution control to the
footwell air vents position.

Recommended Settings for
Heating

Adjust the fan speed to the second
speed setting.

Adjust the temperature control to the
midway point of the hot settings.

Adjust the air distribution control to the
footwell and windshield air vents
position.

Cooling the Interior Quickly

Adjust the fan speed to the highest
speed setting.

Adjust the temperature control to the

MAX A/C

 position.

Adjust the air distribution control to the
instrument panel air vents position.

Recommended Settings for
Cooling

Adjust the fan speed to the second
speed setting.

Adjust the temperature control to the
midway point of the cold settings.

Adjust the air distribution control to the
instrument panel air vents position.

Vehicle Stationary for Extended
Periods During Extreme High
Ambient Temperatures

Apply the parking brake.

Move the transmission selector lever
to position

P

 or neutral.

Adjust the temperature control to the

MAX A/C

 position.

Adjust the fan speed to the lowest
speed setting.

90

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Climate Control
