Anti-Theft Alarm- Page 62

2. Switch the ignition from off to on. Keep

the ignition on for at least three
seconds, but no more than 10 seconds.

3. Switch the ignition off and remove the

first correctly coded key from the
ignition.

4. After three seconds but within 10

seconds of switching the ignition off,
insert the second previously correctly
coded key into the ignition.

5. Switch the ignition from off to on. Keep

the ignition on for at least three
seconds, but no more than 10 seconds.

6. Switch the ignition off and remove the

second previously programmed
correctly coded key from the ignition.

7.

After three seconds but within 10
seconds of switching the ignition off
and removing the previously
programmed correctly coded key,
insert the new unprogrammed key into
the ignition.

8. Switch the ignition from off to on. Keep

the ignition on for at least six seconds.

9. Remove the newly programmed

correctly coded key from the ignition.

If the key has been successfully
programmed it will start the engine and
operate the remote entry system (if the
new key is an integrated keyhead
transmitter).

If the key was not successfully
programmed, wait 10 seconds and repeat
Steps 1 through 8. If you are still
unsuccessful, take your vehicle to an
authorized dealer.

Note:

You can program a maximum of eight

coded keys to your vehicle. All eight can be
integrated keyhead transmitters.

ANTI-THEFT ALARM

Alarm System

The perimeter alarm is a deterrent against
unauthorized access to your vehicle
through the doors, luggage compartment
and the hood.

Triggering the Alarm

Once armed, the alarm is triggered in any
of the following ways:

•

If someone opens a door, cargo area
or the hood without a valid key or
remote control.

•

If you switch the ignition on without a
valid key.

If the alarm is triggered, the horn will sound
for 30 seconds and the hazard warning
flasher will flash for five minutes.

Any further attempts to perform one of the
above will trigger the alarm again.

Arming the Alarm

To arm the alarm, lock your vehicle.  See

Locks

 (page 53).

Disarming the Alarm

Disarm and silence the alarm by unlocking
the doors with the key and switching the
ignition on with a correctly coded key
within 12 seconds, or by unlocking the
doors or the cargo area with the remote
control.

59

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Security
