ENGINE OIL DIPSTICK - 3.5L

E174604

A

B

Minimum

A

Maximum

B

ENGINE OIL DIPSTICK - 3.7L

E174604

A

B

Minimum

A

Maximum

B

ENGINE OIL DIPSTICK - 3.2L
POWER STROKE DIESEL

E71362

A

B

Minimum

A

Maximum

B

ENGINE OIL CHECK

1.

Make sure that your vehicle is on level
ground.

2. Switch off the engine and wait 10

minutes for the oil to drain into the oil
pan.

3. Remove the dipstick and wipe it with

a clean, lint free cloth. Replace the
dipstick and remove it again to check
the oil level.

If the oil level is at the minimum mark, add
oil immediately.  See

Capacities and

Specifications

 (page 265).

Note:

Check the oil level before starting the

engine.

Note:

Make sure that the oil level is

between the minimum and the maximum
marks.

Note:

Do not use oil additives or other

engine treatments. Under certain conditions,
they could damage the engine.

Note:

The oil consumption of new engines

reaches its normal level after approximately
3000 mi (5,000 km).
