CHANGING THE 12V BATTERY

Removing the Battery

WARNINGS

You must replace your vehicle
battery with one of exactly the same
specification.

Make sure the battery box is correctly
sealed.

Your vehicle battery is heavy; take
care when lifting and removing.

Note:

If you have power seats and the

battery has no charge, jump-start your
vehicle to move the seat.  See

Jump

Starting the Vehicle

 (page 177).

Note:

Where applicable you must

reprogram the audio system using the
keycode.

The battery is located inside your vehicle
under the driver seat.

E152526

1

1.

Slide the seat fully forward. Remove
the cover trim by pulling up the tabs
with your fingers.

2

E152529

2. Unhook the cover flap and tuck it under

the seat valance.

E146781

3

4

3. Remove the seat track end caps on

both sides.

4. Remove the seat track rear bolts on

both sides.
