3. Pull the headlamp toward the front of

your vehicle to disengage it from its
locating points and then lift the
headlamp up.

E169200

4. Disconnect the electrical connectors.

Note:

When you install the headlamp, make

sure that you correctly attach the electrical
connector.

Note:

When you install the headlamp, make

sure that you correctly engage its locating
points.

CHANGING A BULB

WARNINGS

Switch all of the lamps and the
ignition off. Failure to follow this
warning could result in serious

personal injury.

WARNINGS

Bulbs become hot when in use. Let
them cool down before you remove
them.

Use the correct specification bulb.  See

Bulb Specification Chart

 (page 221).

The following instructions describe how to
remove the bulbs. Install in the reverse
order unless otherwise stated.

Note:

 LED lamps are not serviceable.  See

an authorized dealer.

Headlamp

E175739

B

C

D

A

Parking lamp and direction
indicator lamp.

A

Headlamp high beam.

B

Headlamp low beam and
daytime running lamp.

C

Side marker lamp.

D

Note:

You may have to remove a cover to

gain access to the bulb.
