Manual Climate Control- Page 92

MANUAL CLIMATE CONTROL

E147011

A

E

B

D

C

Fan speed control:

 Controls the volume of air circulated in your vehicle. Adjust

to select the desired fan speed or switch off. If you switch the fan off, the
windshield may fog up.

A

Recirculated air:

 Press the button to switch between outside air and

recirculated air. When you select recirculated air, the button illuminates and
the air currently in the passenger compartment recirculates. This can reduce
the time needed to cool the interior and reduce unwanted odors from entering
your vehicle.

B

Temperature control:

 Controls the temperature of the air circulated in your

vehicle. Adjust to select the desired temperature. If you select

MAX A/C

, the

system distributes recirculated air through the instrument panel air vents. This
mode is more economical and efficient than normal air conditioning. Turn the
temperature control to maximum heat to turn the auxiliary heater on

C

Air conditioning:

 Press the button to switch the air conditioning on or off. To

improve air conditioning when starting your vehicle, drive with the windows
open for two to three minutes.

D

Air distribution control:

 Adjust to select the desired air distribution.

E

Select to distribute air through
the instrument panel air vents.

Select to distribute air through
the instrument panel air vents
and footwell air vents.

Select to distribute air through
the footwell air vents.

Select to distribute air through
the windshield air vents and
footwell air vents.

89

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Climate Control
