LOAD RETAINING FIXTURES

Securing Cargo

E175810

Maximum Load

Value

Variant

1125 lb (510 kg)

All

Note:

The number of load retaining fixtures

may vary depending on your vehicle model.

LOAD LIMIT

Vehicle Loading - with and
without a Trailer

This section will guide you in the
proper loading of your vehicle,
trailer or both, to keep your loaded
vehicle weight within its design
rating capability, with or without
a trailer. Properly loading your
vehicle will provide maximum
return of vehicle design
performance. Before loading your
vehicle, familiarize yourself with
the following terms for
determining your vehicle’s weight
ratings, with or without a trailer,
from the vehicle’s Tire Label or
Safety Compliance Certification
Label:

Base Curb Weight -

 is the weight

of the vehicle including a full tank
of fuel and all standard
equipment. It does not include
passengers, cargo, or optional
equipment.

Vehicle Curb Weight -

 is the

weight of your new vehicle when
you picked it up from your
authorized dealer plus any
aftermarket equipment.

E143816

PAYLOAD

152
