Navigation- Page 408

Where Am I?

For information about your current
location, select:

Action and Descrip-

tion

Message

View your vehicle's

current location, if

your vehicle is

equipped with

navigation. If your

vehicle is not

equipped with

navigation, nothing

displays.

Where Am I?

NAVIGATION

Note:

The navigation SD card must be in

the SD card slot to operate the navigation
system. If you need a replacement SD card,
see an authorized dealer.

Note:

The SD card slot is spring-loaded. To

remove the SD card, just push the card in
and release it. Do not attempt to pull the
card out to remove it; this could cause
damage.

Your navigation system is comprised of
two main features, destination mode and
map mode.

To set a destination, press the green corner
of your touchscreen, then the

Dest

 button

when it appears. See

Setting a

Destination

 later in this chapter.

To view the navigation map and your
vehicle's current location, touch the green
bar in the upper right-hand corner of the
touchscreen, or, press

Dest

, then

Map

. See

Map mode

 later in this chapter.

Setting a Destination

Press the green corner of your touchscreen,
then the

Dest

 button when it appears.

Choose any of the following:

Destination

Message

My Home

Favorites

Previous Destinations

Point of Interest

Emergency

Street Address

Intersection

City Center

Map

Edit Route

Cancel Route

1.

Enter the necessary information into
the highlighted text fields (in any
order). For address destination entry,
the

Go!

 button appears once you enter

all the necessary information. Pressing
the

Go!

 button makes the address

location appear on the map. If you
choose

Previous Destination

, the last

20 destinations you have selected
appear.

2. Select

Set as Dest

 to make this your

destination. You can also choose to set
this as a waypoint (have the system
route to this point on the way to your
current destination) or save it as a
favorite. The system considers any

Avoid Areas

 selections in its route

calculation.

405
