FUSE SPECIFICATION CHART

Engine Compartment Fuse Box

E148826

Circuits protected

Fuse rating

Fuse

Selective Catalytic Reduction - Diesel.

10A

Selective Catalytic Reduction - Diesel.

15A

Selective Catalytic Reduction - Diesel.

15A

Selective Catalytic Reduction - Diesel.

10A

187

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Fuses
