Lane Keeping System- Page 152

System Warnings

Note:

The system will not issue warnings

below approximately 40 mph (65 km/h).

The warning system has two stages:
1.

A temporary warning is issued to advise
you to take a rest. This message only
appears for a short time.

2. If you do not rest and the system

continues to detect that your driving
deteriorates, it will issue a further
warning. This will remain in the
information display until you cancel it.
See

Information Messages

 (page

83).

Press

OK

 on the steering wheel control to

remove the warning.

System Display

When active the system will run
automatically in the background and only
issue warnings if required. You can view
the status at any time using the
information display.  See

General

Information

 (page 78).

The alertness level is shown by six steps
as a colored bar.

E131358

Alertness level is fine, no rest required.

E131359

Alertness level is critical, indicating that
you should take a rest as soon as it is safe
to do so.

The status bar will travel from left to right
as the calculated alertness level
decreases. As the rest icon is approached
the color turns from green to yellow and
then finally red when a rest break must be
taken.

•

Green: No rest required.

•

Yellow: First (temporary) warning.

•

Red: Second warning.

Your alertness level will be shown in grey
if:
•

the camera sensor cannot track the
road lane markings

•

your vehicle speed drops below
approximately 40 mph (65 km/h).

Resetting the System

You can reset the system by:
•

switching the ignition off and on

•

stopping your vehicle and then opening
and closing the driver's door.

LANE KEEPING SYSTEM

Lane Keeping Alert

Principle of Operation

WARNINGS

The system does not relieve you of
your responsibility to drive with due
care and attention.

At all times you are responsible for
controlling your vehicle, supervising
the system and intervening if

required.

If the sensor becomes blocked the
system may not function.

149

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Driving Aids
