Vehicle Care

Fuses

Usage

62

ICCM/CVS/DEF

–

Integrated Chassis
Control Module/Canister
Vent Solenoid/Diesel
Exhaust Fluid

63

Trailer Brake

65

AUX UEC

–

Auxiliary

Underhood Electrical
Center

66

Left Cool Fan Motor

67

AFM 2

–

Active Fuel

Management 2

68

Automatic Lamp Control
(ALC) Motor

69

Starter Pinion

71

Cool Fan Motor Lower

72

Right Cool Fan Motor/
Lower

73

Left Trailer Stop
Turn Lamp

74

TIM 2

–

Trailer Interface

Module 2

75

DEFC

–

Diesel Exhaust

Fluid Controller

Fuses

Usage

76

ELEC RNG BDS

78

ECM

–

Engine Control

Module

79

–

80

Cabin Cool Pump 17W

81

Right Trailer Stop
Turn Lamp

82

TIM 1

–

Trailer Interface

Module 1

83

FTZM

–

Fuel Tank Zone

Module

84

Trailer Battery

85

Engine

86

ECM

–

Engine Control

Module

87

Injector B Even

88

02 B Sensor

89

02 A Sensor

90

Injector A Odd

91

Engine Control Module
(ECM) Throttle Control

Fuses

Usage

92

Cool Fan Clutch AERO
Shutter

Relays

Usage

5

–

18

DC/AC Inverter

23

–

35

Park Lamp

36

Run/Crank

43

Secondary Axle Motor

59

A/C Clutch

64

Starter Motor

70

Starter Pinion

77

Powertrain
