System Warnings; Setting the System Sensitivity- Page 154

Setting the System Sensitivity

You can adjust how quickly the system
warns you of a dangerous situation. The
system has two sensitivity levels which you
can set using the information display.  See
(page 78).

System Warnings

E152382

A column of lane markings are displayed
either side of the vehicle graphic.

The lane markings are color coded as
follows:
•

Green: The system is ready to warn you
of any unintentional lane departure.

•

Red: Your vehicle is approaching or is
too close to the detected lane
boundary. Take immediate safe action
to reposition your vehicle.

•

Gray: The system will suppress the
relevant lane boundary.

Instances where a lane boundary may be
suppressed:
•

The sensor may not detect the lane
markings on the road.

•

You turn the direction indicator for that
side of your vehicle on.

•

If you apply direct steering, accelerate
fast or brake hard.

•

Your vehicle speed is outside the
operating limits.

•

If there is an anti-lock brake or stability
control intervention.

•

Narrow lane width.

If the lane markings in the display turn red
or you feel a vibration through the steering
wheel you must take immediate and safe
action to align your vehicle. Correct any
unintended lane drift immediately.

151

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Driving Aids
