Brake Fluid Check- Page 214

E177378

2

1

1.

Attach a tube to the drain plug and
place the end of the tube into a
suitable container.

2. Loosen the drain plug by turning

counterclockwise one to two turns and
allow the water to drain.

Note:

The drain plug will rise when opening.

3. Tighten the drain plug by turning

clockwise until you feel a strong
resistance.

Note:

The drain plug will lower when

closing.

When you start the engine the water in fuel
indicator lamp turns off after a short period
of time.

Changing the Fuel Filter

Note:

To drain the fuel filter, access the

underside of your vehicle.

1.

Drain the fuel from the filter housing.

E184430

2

3

2. Disconnect the electrical connector.

3. Rotate the housing counterclockwise

to the unlock position.

4. Remove the housing and filter.

5. Replace the housing seal and lubricate.

6. Insert the new filter into housing and

refit aligning the arrows in the unlock
position.

211

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Maintenance
