Changing the Engine Air Filter- Page 229

E177562

3

5

4. Carefully lift the air filter housing cover.

Remove the air filter element from the
air filter housing.

5. Install a new air filter element. Make

sure that the groove seal on the
pleated paper filter traps both sides of
the vertical partition of the air box.

6. Replace the air filter housing. Engage

the clamps that secure the air filter
housing cover to the air filter housing.
Be careful not to crimp the filter
element edges between the air filter
housing and cover. Make sure that the
tabs on the edge are correctly aligned
into the slots.

7.

Slip the air tube onto the air filter cover
and snugly tighten the bolt on the air
tube clamp, but do not overtighten.

8. Reconnect the mass air flow sensor

electrical connector to the outlet tube.
Make sure the locking tab on the
connector is in the locked position.

226

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Maintenance
