Car Finder- Page 47

E138615

Note:

Your vehicle’s keys came with a

security label that provides important
vehicle key cut information. Keep the label
in a safe place for future reference.

Programming a New Remote
Control

To program an additional remote control
See

Passive Anti-Theft System

 (page

58).

Replacing the Battery

The remote control uses one coin type
three volt lithium battery CR2032 or
equivalent.

Note:

Refer to local regulations when

disposing of transmitter batteries.

Note:

Do not wipe off any grease on the

battery terminals or on the back surface of
the circuit board.

Note:

Replacing the battery will not delete

the transmitter from the vehicle. The
transmitter should operate normally.

Integrated Key head Transmitter

E138619

1.

Twist a thin coin in the slot of the
transmitter near the key ring to remove
the battery cover.

2. Remove the old battery.

E138620

3. Insert the new battery. Refer to the

instructions inside the transmitter for
the correct orientation of the battery.
Press the battery down to make sure
it is fully in the housing.

4. Snap the battery cover back onto the

transmitter.

Car Finder

Press the lock button on the key twice
within three seconds. The horn sounds and
the direction indicators will flash. We
recommend you use this method to locate
your vehicle, rather than using the panic
alarm.

44

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Keys and Remote Controls
