Coolant Check- Page 76

If the needle enters the red section, the
engine is overheating. Stop your vehicle as
soon as it is safe to do so and switch the
engine off. Determine the cause once the
engine has cooled down.  See

Engine

Coolant Check

 (page ?).

Note:

Do not restart the engine until the

cause of overheating has been determined
and resolved.

Tripmeter Reset and Distance to
Empty

 (If Equipped)

Press the button to change between the
tripmeter and distance to empty
information.  Press and hold the button to
reset the tripmeter.

Fuel Gauge

Note:

The fuel gauge may vary slightly

when your vehicle is moving or on a gradient.

Switch the ignition on.  The fuel gauge will
indicate approximately how much fuel is
in the fuel tank.  The arrow adjacent to the
fuel pump symbol indicates on which side
of your vehicle the fuel filler door is located.

The needle should move toward F when
you refuel your vehicle. If the needle points
to E after adding fuel, this indicates your
vehicle needs service soon.

After refueling some variability in needle
position is normal:

•

It may take a short time for the needle
to reach F after leaving the gas station.
This is normal and depends upon the
slope of pavement at the gas station.

•

The fuel amount dispensed into the
tank is a little less or more than the
gauge indicated. This is normal and
depends upon the slope of pavement
at the gas station.

•

If the gas station nozzle shuts off
before the tank is full, try a different
gas pump nozzle.

Low Fuel Reminder

A low fuel reminder triggers when the fuel
gauge needle is at 1/16th.

Variations:

Distance-to-empty

Fuel gauge position

Driving type (fuel economy

conditions)

35 miles to 80 miles (56 km

to 129 km)

1/16th

Highway driving

35 miles (56km)

1/16th

Severe duty driving (trailer

towing, extended idle)

73
