Parking Aids- Page 148

E142132

A

B

C

A

B

C

D

Red - up to 12 inches (0.3 meter).

A

Amber - 12 inches to 24 inches
(0.3 meter to 0.6 meter).

B

Green - 24 inches to 35 inches
(0.6 meter to 0.9 meter).

C

Black - center line of the
projected vehicle path.

D

Note:

The green line is extended from 35 in

(0.9 m) up to a distance of 126 in (3.2 m).

Note:

When reversing with a trailer the

camera will show the direction of your
vehicle and not the direction of the trailer.

Note:

When reversing with a trailer the

screen does not display the lines.

Switching the Rear View Camera
Off

Move the gearshift lever from reverse (R).

Note:

The system will automatically switch

once your vehicle speed has reached
approximately 5 mph (8 km/h) or after a
short period of time.

Vehicles with Parking Aid

The display will show a colored distance
bar.  This indicates the approximate
distance from the rear bumper to an
object.

These are color coded as follows:
•

Red - up to 12 in (0.3 m).

•

Amber - 12 in (0.3 m) to 24 in (0.6 m).

•

Green - 24 in (0.6 m) to 71 in (1.8 m).
