Parking Aids- Page 147

WARNINGS

The operation of the camera may
vary depending on the ambient
temperature, vehicle and road

conditions.

Do not place objects in front of the
camera.

The camera may not detect objects
that are very close to your vehicle.

E170301

The camera is on the rear cargo door.

Switching the Rear View Camera
On

Switch the ignition on and shift into reverse
(R). The image will display in the interior
mirror or in the information and
entertainment display.

The camera may not operate correctly in
any of the following conditions:
•

Dark areas.

•

Intense light areas.

•

If there is a sudden change to the
ambient temperature.

•

If the camera is wet.

•

If the camera is dirty.

•

If the camera is obstructed.

Using the Display

WARNING

Objects above the camera may not
be visible. Check the area behind
your vehicle when necessary.

The lines show a projected vehicle path
and the approximate distance from the
rear bumper to an object.

Distance markers are only a guide and are
calculated for unloaded vehicles on an
even road surface.

144

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Parking Aids

 (If Equipped)
