Pre-fuse Box- Page 198

Circuits protected

Fusible link

rating

Fusible link

Body control module fuse box.

Powertrain control module.

40A

E

Anti-lock brake system.

Passenger compartment fuse panel.

200A

F

Passenger compartment fuse panel.

100A

G

Positive temperature coefficient heater.

80A

H

Not used.

-

J

Engine junction box feed.

100A

K

Passenger compartment fuse panel.

100A

L

Passenger compartment fuse panel supply.

60A

M

Passenger compartment fuse panel supply.

60A

N

Auxiliary power point 1.

60A

P

Auxiliary power point 2.

60A

R

Auxiliary power point 3.

60A

S

Circuits protected

Fuse rating

Fuse

Not used.

-

F1

Not used.

-

F2

Not used.

-

F3

Not used.

-

F4

R4 relay power.

20A

F5

R3 relay power.

20A

F6

R2 relay power.

20A

F7

R1 relay power.

20A

F8

Not used.

-

F9

195

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Fuses
