Central High Mounted Brake Lamp- Page 223

3

E175745

3. Turn the bulb holder counterclockwise

and remove it.

A

B

C

4

E175746

Tail and brake lamp.

A

Reversing lamp.

B

Rear clearance lamp.

C

4. Remove the bulb by pulling it straight
out.

Central High Mounted Brake Lamp

This is not a serviceable item, see an
authorized dealer if it fails.

License Plate Lamp

3

2

1

E72789

1.

Carefully release the spring clip.

2. Remove the lamp.
3. Turn the bulb holder counterclockwise

and remove it. Pull the bulb straight
out.

Interior Lamp

Vehicles with Interior Sensors

1

2

E154370

1.

Carefully remove the lens.

2. Remove the bulb.

220

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Maintenance
