Side Marker Lamp- Page 221

Side Marker Lamp

3

E175740

2

1.

Remove the headlamp.  See

Removing a Headlamp

 (page 216).

2. Turn the bulb holder counterclockwise

and remove it.

3. Remove the bulb by pulling it straight

out.

Parking Lamp and Direction Indicator
Lamp

3

E175741

2

1.

Remove the headlamp.  See

Removing a Headlamp

 (page 216).

2. Turn the bulb holder counterclockwise

and remove it.

3. Remove the bulb by pulling it straight

out.

Headlamp Low Beam and Daytime
Running Lamp

4

3

2

E175742

1.

Remove the headlamp.  See

Removing a Headlamp

 (page 216).

2. Remove the cover.

3. Turn the bulb counterclockwise and

remove it.

4. Disconnect the electrical connector.

Note:

Do not touch the bulb glass.

Note:

You cannot separate the bulb from

the bulb holder.

Headlamp High Beam

4

3

2

E175743

1.

Remove the headlamp.  See

Removing a Headlamp

 (page 216).

2. Remove the cover.

3. Turn the bulb counterclockwise and

remove it.

218

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Maintenance
