4. Disconnect the electrical connector.

Note:

Do not touch the bulb glass.

Note:

You cannot separate the bulb from

the bulb holder.

Front Clearance Lamp

 (If Equipped)

E181397

2

1

1.

Carefully remove the lamp.

2. Turn the bulb holder counterclockwise

and remove it.

3. Remove the bulb by pulling it straight

out.

Side Direction Indicator

 (If Equipped)

E169209

3

1

4

5

2

1.

Remove the large mirror glass. Tilt the
mirror glass fully up, pull the mirror
glass toward you from the bottom.

2. Remove the small mirror glass. Tilt the

mirror glass fully down, pull the mirror
glass toward you from the top.

3. Remove the screws.
4. Remove the lamp lens.

5. Remove the bulb.

Rear Lamps

E175758

2

1

1.

Remove the screws.

2. Remove the lamp.

219
