Compliance Label.- Page 261

Note:

If your vehicle is fitted with a tire

pressure monitoring system, the warning
indicator will flash if you fit the spare wheel
to your vehicle. To restore the correct
operation of the tire pressure monitoring
system, you must have the repaired road
wheel and tire assembly refitted to your
vehicle.  See

Tire Pressure Monitoring

System

 (page 251).  To prevent damage

occurring to the tire pressure monitoring
system sensors, make sure you have a
damage tire repaired or replaced by a tire
professional.

E145138

1.

Open the rear doors. Remove the
grommet and insert the flat end of the
lug wrench into the socket. Turn
counterclockwise until the spare wheel
rests on the ground and the cable is
loose.

E146811

2. Raise the cable end cover.

E146812

1

2

3. Rotate the cable through 90 degrees.

Slide the cable through the slot to
release the spare wheel bracket from
the winch.

258

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Wheels and Tires
