Compliance Label.- Page 262

E146813

4. Remove the retaining nut to release

the spare wheel bracket.

Vehicles With a Spare Wheel

Chassis Cab and Cutaway

The spare wheel is under the rear of your
vehicle.

If the spare wheel is the same type and
size as your vehicle road wheel, you can fit
the spare wheel and continue to drive in
the normal manner.

If the spare wheel is not the same type and
size as your vehicle road wheel, it has a
label showing the maximum driving speed
limit.

Note:

If your vehicle is fitted with a tire

pressure monitoring system, the warning
indicator will flash if you fit the spare wheel
to your vehicle. To restore the correct
operation of the tire pressure monitoring
system, you must have the repaired road
wheel and tire assembly refitted to your
vehicle.  See

Tire Pressure Monitoring

System

 (page 251).  To prevent damage

occurring to the tire pressure monitoring
system sensors, make sure you have a
damage tire repaired or replaced by a tire
professional.

E184880

1.

Insert the flat end of the lug wrench
into the socket. Turn counterclockwise
until the spare wheel rests on the
ground and the cable is loose.

E146811

2. Raise the cable end cover.

259

Transit (TTH) Canada/United States of America, enUSA, Edition date: 03/2014, Third Printing

Wheels and Tires
