Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

INSTRUMENTS AND CONTROLS

105

Controls

Steering Wheel Adjustment

To adjust the steering wheel:

1. Pull the lever down.

2. Move the steering wheel up

or down.

3. Pull or push the steering wheel

closer or away from you.

4. Pull the lever up to lock the

steering wheel in place.

Power Tilt and Telescoping Wheel

If equipped, the control is on the left
side of the steering column.

.

Push the control up or down to tilt
the steering wheel up or down.

.

Push the control forward or
rearward to move the steering
wheel toward the front or rear of
the vehicle.

Do not adjust the steering wheel while
driving.

To set the power tilt wheel memory
position, see

Memory Seats

0

58

.

Steering Wheel Controls

The infotainment system can be
operated by using the steering wheel
controls. See

Steering Wheel

Controls

in the infotainment manual.

Heated Steering Wheel

(

:

If equipped, press to turn the

heated steering wheel on or off. An
indicator light next to the button
displays when the feature is
turned on.

The steering wheel takes about
three minutes to be fully heated.
