Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

314

VEHICLE CARE

6. Connect the other end of the red

positive (+) cable to the
positive (+) terminal of the good
battery.

7. Connect one end of the black

negative (

) cable to the

negative (

) terminal of the good

battery.

8. Connect the other end of the

black negative (

) cable to the

negative (

) grounding point for

the discharged battery.

9. Start the engine in the vehicle

with the good battery and run
the engine at idle speed for at
least four minutes.

10. Try to start the vehicle that had

the dead battery. If it will not
start after a few tries, it probably
needs service.

Caution

If the jumper cables are connected
or removed in the wrong order,
electrical shorting may occur and
damage the vehicle. The repairs
would not be covered by the vehicle
warranty. Always connect and
remove the jumper cables in the
correct order, making sure that the
cables do not touch each other or
other metal.

Jumper Cable Removal

Reverse the sequence exactly when
removing the jumper cables.

After starting the disabled vehicle and
removing the jumper cables, allow it
to idle for several minutes.

Towing the Vehicle

Caution

Incorrectly towing a disabled
vehicle may cause damage. The
damage would not be covered by
the vehicle warranty. Do not lash or
hook to suspension components.
Use the proper straps around the
tires to secure the vehicle. Do not
drag a locked wheel/tire while
loading the vehicle. Do not use a
sling type lift to tow the vehicle.
This could damage the vehicle.

GM recommends a flatbed tow truck
to transport a disabled vehicle. Use
ramps to help reduce approach angles,
if necessary. A towed vehicle should
have its drive wheels off the ground.
Contact Roadside Service or a
professional towing service if the
disabled vehicle must be towed.
