Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

IN BRIEF

23

If equipped, this system provides a
way to replace up to three remote
control transmitters used to activate
devices such as garage door openers,
security systems, and home
automation devices.

Read the instructions completely
before attempting to program the
Universal Remote system. Because of
the steps involved, it may be helpful
to have another person available to
assist you with programming the
Universal Remote system.

See

Universal Remote System

0

140

.

Sunroof

If equipped with a sunroof, the
ignition must be on or in ACC/
ACCESSORY, or Retained Accessory
Power (RAP) must be active, to
operate the sunroof.
See

Ignition Positions

0

185

and

Retained Accessory Power (RAP)

0

190

.

1. SLIDE Switch
2. TILT Switch

Slide Switch

Express-Open/Express-Close :

Press

D

(1) to the second detent and

release to express-open the sunroof.
Press

g

(1) to the second detent

and release to express-close the
sunroof. Press again to stop the
movement.

Open/Close (Manual Mode) :

Press

D

(1) to the first detent and

hold to open the sunroof. Press

g

(1) to the first detent and hold to
close the sunroof. Release to stop the
movement.

Tilt Switch

Vent Feature :

Press and hold

E

(2)

to vent the sunroof. The sunshade
must be manually opened. Press and
hold

g

(2) to close the

sunroof vent.

The sunroof is equipped with an
automatic reversal system. See

Sunroof

0

49

.
