Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

VEHICLE CARE

269

Park Brake and P (Park)
Mechanism Check

{

Warning

When you are doing this check, the
vehicle could begin to move. You or
others could be injured and
property could be damaged. Make
sure there is room in front of the
vehicle in case it begins to roll. Be
ready to apply the regular brake at
once should the vehicle begin
to move.

Park on a fairly steep hill, with the
vehicle facing downhill. Keeping your
foot on the regular brake, set the
parking brake.

.

To check the parking brake's
holding ability: With the engine
running and the transmission in
N (Neutral), slowly remove foot
pressure from the regular brake
pedal. Do this until the vehicle is
held by the parking brake only.

.

To check the P (Park) mechanism's
holding ability: With the engine
running, shift to P (Park). Then
release the parking brake followed
by the regular brake.

Contact your dealer if service is
required.

Wiper Blade Replacement

Windshield wiper blades should be
inspected for wear and cracking. See

Maintenance Schedule

0

327

.

Replacement blades come in different
types and are removed in different
ways. For proper type and length, see

Maintenance Replacement Parts

0

338

.

Caution

Allowing the wiper arm to touch
the windshield when no wiper blade
is installed could damage the
windshield. Any damage that occurs
would not be covered by the vehicle
warranty. Do not allow the wiper
arm to touch the windshield.

To replace the windshield wiper blade:

1. Pull the windshield wiper

assembly away from the
windshield.

2. Lift up on the latch in the middle

of the wiper blade where the
wiper arm attaches.

3. With the latch open, pull the

wiper blade down toward the
windshield far enough to release
it from the J-hooked end of the
wiper arm.

4. Remove the wiper blade.

5. Reverse Steps 1

–

3 for wiper

blade replacement.
