Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

LIGHTING

149

If after signaling a turn or lane
change, the arrow flashes rapidly or
does not come on, a signal bulb might
be burned out.

Replace any burned out bulbs. If a
bulb is not burned out, check the fuse.
See

Fuses and Circuit Breakers

0

274

.

Interior Lighting

Instrument Panel
Illumination Control

The brightness of the instrument
panel lighting and steering wheel
controls can be adjusted.

D

:

Move the thumbwheel up or

down to brighten or dim the lights.

The brightness of the displays
automatically adjusts based on
outdoor lighting. The instrument
panel illumination control will set the
lowest level to which the displays will
automatically be adjusted.

Courtesy Lamps

The courtesy lamps come on when
any door is opened and the dome
lamp is in the DOOR position.

Dome Lamps

The dome lamp is in the overhead
console.

To change the dome lamp settings,
press:

OFF :

Turns the lamp off, even when a

door is open.

DOOR :

The lamp comes on when a

door is opened.
