Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

274

VEHICLE CARE

Headlamp Wiring

An electrical overload may cause the
lamps to go on and off, or in some
cases to remain off. Have the
headlamp wiring checked right away if
the lamps go on and off or remain off.

Windshield Wipers

If the wiper motor overheats due to
heavy snow or ice, the windshield
wipers will stop until the motor cools
and will then restart.

Although the circuit is protected from
electrical overload, overload due to
heavy snow or ice may cause wiper
linkage damage. Always clear ice and
heavy snow from the windshield
before using the windshield wipers.

If the overload is caused by an
electrical problem and not snow or
ice, be sure to get it fixed.

Fuses and Circuit Breakers

The wiring circuits in the vehicle are
protected from short circuits by a
combination of fuses and circuit

breakers. This greatly reduces the
chance of damage caused by electrical
problems.

{

Danger

Fuses and circuit breakers are
marked with their ampere rating.
Do not exceed the
specified amperage rating when
replacing fuses and circuit breakers.
Use of an oversized fuse or circuit
breaker can result in a vehicle fire.
You and others could be seriously
injured or killed.

To check a fuse, look at the
silver-colored band inside the fuse.
If the band is broken or melted,
replace the fuse. Be sure to replace a
bad fuse with a new one of the
identical size and rating.

Fuses of the same amperage can be
temporarily borrowed from another
fuse location, if a fuse goes out.
Replace the fuse as soon as possible.

Engine Compartment Fuse
Block

The engine compartment fuse block is
on the passenger side of the engine
compartment.

Lift the fuse block cover to access the
fuses.

The vehicle may not be equipped with
all of the fuses and relays shown.
