Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

148

LIGHTING

Adaptive Forward
Lighting (AFL)

On vehicles with the AFL system, the
headlamps pivot horizontally to
provide greater road illumination
while turning. To enable AFL, set the
exterior lamp control on the turn
signal lever to the AUTO position. To
adjust the AFL setting, see

Vehicle

Personalization

0

135

. Moving the

control out of the AUTO position will
deactivate the system. AFL will
operate when the vehicle speed is
greater than 3 km/h (2 mph). AFL will
not operate when the transmission is
in R (Reverse). AFL is not immediately
operable after starting the vehicle;
driving a short distance is required to
calibrate the AFL. See

Exterior Lamp

Controls

0

144

.

This feature can be changed, see

Vehicle Personalization

0

135

.

Hazard Warning Flashers

|

:

Press to make the front and rear

turn signal lamps flash on and off.
Press again to turn the flashers off.

The hazard warning flashers turn on
automatically if the airbags deploy.

Turn and Lane-Change
Signals

Move the lever all the way up or down
to signal a turn.

An arrow on the instrument cluster
flashes in the direction of the turn or
lane change.

Raise or lower the lever until the
arrow starts to flash to signal a lane
change. Hold it there until the lane
change is completed. If the lever is
briefly pressed and released, the turn
signal flashes three times.

The turn and lane-change signal can
be turned off manually by moving the
lever back to its original position.
