Cadillac ATS/ATS-V Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-

12460272) - 2019 - crc - 5/8/18

46

KEYS, DOORS, AND WINDOWS

Memory Mirrors

The vehicle may have exterior
memory mirrors. See

Memory Seats

0

58

.

Side Blind Zone Alert (SBZA)

The vehicle may have Side Blind Zone
Alert. See

Side Blind Zone Alert (SBZA)

0

232

.

Turn Signal Indicator

If equipped with turn signal indicators
on the mirror housings, the indicator
will flash when a turn signal or the
hazard warning flashers are used.

Folding Mirrors

Manual Folding Mirrors

The mirrors can be folded inward
toward the vehicle to prevent damage
when going through an automatic
car wash.

Push the mirror outward to return it
to the original position.

Heated Mirrors

K

:

Press to heat the mirrors.

See

Rear Window Defogger

under

Dual Automatic Climate Control System
(Base)

0

158

or

Dual Automatic Climate

Control System (Uplevel)

0

162

.

Reverse Tilt Mirrors

If equipped with memory seats, the
passenger and/or driver mirror tilts to
a preselected position when the
vehicle is in R (Reverse). This allows
the curb to be seen when parallel
parking.

The mirror(s) return to the original
position when:

.

The vehicle is shifted out of
R (Reverse), or remains in
R (Reverse) for about 30 seconds.

.

The ignition is turned off.

.

The vehicle is driven in
R (Reverse) above a set speed.

To turn this feature on or off, see

Vehicle Personalization

0

135

.

Interior Mirrors

Interior Rearview Mirrors

Adjust the rearview mirror for a clear
view of the area behind the vehicle.

Do not spray glass cleaner directly on
the mirror. Use a soft towel dampened
with water.

Manual Rearview Mirror

If equipped with a manual rearview
mirror, push the tab forward for
daytime use and pull it for nighttime
use to avoid glare from the headlamps
from behind.

Automatic Dimming
Rearview Mirror

If equipped, automatic dimming
reduces the glare of headlamps from
behind. The dimming feature comes
on when the vehicle is started.
