SAFETY

275

Center Seat LATCH

This vehicle has 4 lower LATCH anchorages in the

third row, rear seat. Anchorages A and B are used

for the right outboard position behind the front

passenger (1). Anchorages C and D are used for

the center seating position (2). The left outboard

position (3) does not have lower anchorages. Do

not install a child restraint using anchorages B and

C. This is not a LATCH position in your vehicle.

Center Seat LATCH Positions

If a child restraint installed in the center position

blocks the seat belt webbing or buckle for the

outboard position, do not use that outboard

position. If a child seat in the center position blocks

the outboard LATCH anchors or seat belt, do not

install a child seat in that outboard position.

Always follow the directions of the child restraint

manufacturer when installing your child restraint.

Not all child restraint systems will be installed as

described here.

To Install A LATCH-Compatible Child

Restraint

If the selected seating position has a Switchable

Automatic Locking Retractor (ALR) seat belt, stow

the seat belt, following the instructions below. See

Ú

page 276 to check what type of seat belt each

seating position has.

1. Loosen the adjusters on the lower straps and

on the tether strap of the child seat so that

you can more easily attach the hooks or

connectors to the vehicle anchorages.

2. Place the child seat between the lower

anchorages for that seating position. If the

second row seat can be reclined, you may

recline the seat and/or raise the head restraint

(if adjustable) to get a better fit. If the rear seat

can be moved forward and rearward in the

vehicle, you may wish to move it to its

rear-most position to make room for the child

seat. You may also move the front seat forward

to allow more room for the child seat.

3. Attach the lower hooks or connectors of the

child restraint to the lower anchorages in the

selected seating position.

4. If the child restraint has a tether strap, connect

it to the top tether anchorage. See

Ú

page 280 for directions to attach a tether

anchor.

5. Tighten all of the straps as you push the child

restraint rearward and downward into the

seat. Remove slack in the straps according to

the child restraint manufacturer’s instructions.

6. Test that the child restraint is installed tightly

by pulling back and forth on the child seat at

the belt path. It should not move more than

1 inch (25.4 mm) in any direction.

WARNING!

Use anchorages C and D to install a

LATCH-compatible child restraint in the center

seating position (2). Do not install a

LATCH-compatible child restraint using

anchorages B and C. This is not a

LATCH-compatible position in your vehicle.

Never use the same lower anchorage to

attach more than one child restraint. Please

see

Ú

page 275 for typical installation

instructions.

6

21_RUP_OM_EN_USC_t.book  Page 275

Detailed Information for 2021 Chrysler Pacifica Owner's Manual

Lists of information found in 2021 Chrysler Pacifica Owner's Manual - Page 277

  • 1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so that you can more easily attach the hooks or connectors to the vehicle anchorages.
  • 2. Place the child seat between the lower anchorages for that seating position.
  • 3. Attach the lower hooks or connectors of the child restraint to the lower anchorages in the selected seating position.
  • 4. If the child restraint has a tether strap, connect it to the top tether anchorage.
  • 5. Tighten all of the straps as you push the child restraint rearward and downward into the seat.
  • 6. Test that the child restraint is installed tightly by pulling back and forth on the child seat at the belt path.
  • 25.4 mm) in any direction.
