background image

362

TECHNICAL SPECIFICATIONS

VEHICLE IDENTIFICATION NUMBER (VIN)

The VIN is on the left front corner of the instrument

panel and is visible from outside of the vehicle

through the windshield.

Vehicle Identification Number

NOTE:

It is illegal to remove or alter the VIN.

BRAKE SYSTEM

Your vehicle is equipped with dual hydraulic brake

systems. If either of the two hydraulic systems

loses normal capability, the remaining system will

still function. However, there will be some loss of

overall braking effectiveness. You may notice

increased pedal travel during application, greater

pedal force required to slow or stop, and potential

activation of the Brake Warning Light.
In the event power assist is lost for any reason (i.e.,

repeated brake applications with the engine off)

the brakes will still function. However, the effort

required to brake the vehicle will be much greater

than that required with the power system

operating.

WHEEL AND TIRE TORQUE SPECIFICATIONS

Proper lug nut/bolt torque is very important to

ensure that the wheel is properly mounted to the

vehicle. Any time a wheel has been removed and

reinstalled on the vehicle, the lug nuts/bolts

should be torqued using a properly calibrated

torque wrench using a six sided (hex) deep wall

socket.

T

ORQUE

 S

PECIFICATIONS

**Use only authorized dealer recommended lug

nuts/bolts and clean or remove any dirt or oil

before tightening.
Inspect the wheel mounting surface prior to

mounting the tire and remove any corrosion or

loose particles.

Wheel Mounting Surface

Lug Nut/Bolt

Torque

**Lug Nut/

Bolt Size

Lug Nut/Bolt

Socket Size

100 Ft-Lb

(135 N·m)

M12 x 1.5

19 mm
