340

SERVICING AND MAINTENANCE



Replacing Exterior Bulbs

FRONT TURN SIGNAL LAMP

See below steps to replace:
1. Open the hood.
2. Twist the front turn signal lamp socket

assembly counterclockwise, and then remove

the front turn signal lamp assembly from the

lamp housing.

Front Turn Signal Lamp Socket

3. Pull the bulb out of the socket and insert the

replacement bulb.

4. Install the front turn signal lamp socket

assembly into the housing, and rotate the front

turn signal lamp socket clockwise to lock it in

place.

FRONT AND REAR SIDE MARKER LAMPS

See below steps to replace:
1. Remove the three fasteners from the inner

wheel liner and carefully peel back liner for

access.

Inner Wheel Liner Fasteners

2. Firmly grab the front side marker lamp socket

and rotate a quarter turn counterclockwise to

remove it from the lamp assembly.

Front Side Marker Lamp Bulb Removal

3. Remove bulb from the front side marker lamp

socket and replace with a new bulb.

4. Install front side marker lamp socket in lamp

assembly and rotate a quarter turn clockwise

to lock into place.

5. Position the inner wheel liner in place and

install the three fasteners.
