322

SERVICING AND MAINTENANCE



3. There are glove compartment travel stops on

either side of the glove compartment door. To

release them, push inward on each travel stop,

and pull the glove compartment door down

until the travel stops pass clear of their

hooking points.

4. Open the glove compartment door as far as

possible to gain access to the cabin air filter

compartment cover.

Cabin Air Filter Compartment Cover

5. Pry up the lid of each individual compartment

snap, and detach it from the rest of the snap.

There is a small space on the side of each

snap to use for separating the lid from the

snap. Once detached, remove the rest of the

snap completely from the compartment cover.

6. After removing the snaps, lift up the

compartment cover to gain access to the fresh

air inlet.

Fresh Air Inlet

7. Remove the filter cover by prying back each of

the retaining tabs from their hooking points,

and then pulling the filter cover out to expose

the cabin air filter. Remove the air filter by

pulling it straight out of the housing.

8. Install the new air filter with the arrow on the

filter pointing toward the floor.

9. Once the filter is replaced, reinstall the filter

cover, making sure the retaining tabs are fully

secured into their housings.

10. Close the cabin air filter compartment cover,

and reinsert the snaps into their slots. Push

the snap lids until fully attached.

11. Push the glove compartment door to the near

closed position to reengage the glove

compartment travel stops. Finally, pull the

glove compartment tension tether clip down

and slide it back into the slot on the side of the

glove compartment door.

1 — Compartment Cover
2 — Compartment Snap

1 — Filter Cover
2 — Retaining Tabs



CAUTION!

The cabin air filter is identified with an arrow to

indicate airflow direction through the filter.

Failure to properly install the filter will result in

the need to replace it more often.
