IN CASE OF EMERGENCY

301

If the tire inflates to the recommended pressure or

is at least 26 psi (1.8 Bar) pressure within

15 minutes:

NOTE:

If the tire becomes overinflated, push the Deflation

Button to reduce the tire pressure to the recom

-

mended inflation pressure before continuing.

1. Push the Power Button to turn the

Tire Service Kit off.

2. Remove the speed limit label from

the Tire Service Kit and place sticker

on the steering wheel.

3. Immediately disconnect the Sealant Hose

from the valve stem, reinstall the cap on the

fitting at the end of the hose, and place the Tire

Service Kit in the vehicle storage location.

Drive Vehicle:

 Immediately after injecting sealant and

inflating the tire, drive the vehicle 5 miles

(8 km) or 10 minutes to ensure

distribution of the Tire Service Kit Sealant

within the tire. Do not exceed 50 mph (80 km/h).

After Driving:

Pull over to a safe location and turn on the

vehicle’s Hazard Warning Flashers.

Verify that the valve stem (on the wheel with the

deflated tire) is in a position that is near to the

ground. This will allow the Tire Service Kit Hose

to reach the valve stem and keep the Tire

Service Kit flat on the ground. This will provide

the best positioning of the kit when injecting the

sealant into the deflated tire and running the air

pump. Move the vehicle as necessary to place

the valve stem in this position before

proceeding.

Place the transmission in PARK (P) and cycle the

ignition in the OFF position.

Apply the parking brake.

NOTE:

If tire has improper inflation follow the steps below
1. Uncoil the Sealant Hose, and then remove the

cap from the fitting at the end of the hose.

2. Place the Tire Service Kit flat on

the ground next to the deflated tire.

3. Remove the cap from the valve stem, and then

screw the fitting at the end of the Sealant Hose

onto the valve stem.

4. Uncoil the Power Plug and insert

the plug into the vehicle's 12 Volt

power outlet.
5. Uncoil the Hose and screw the

fitting at the end of the hose onto the

valve stem.
6. Turn the Mode Select Knob and

turn to the Air Mode position.
7.Check the pressure in the tire by

reading the Pressure Gauge.

If tire pressure is less than 19 psi (1.3 Bar):
The tire is too badly damaged. Do not attempt to

drive the vehicle further. Call for assistance.

WARNING!

The Tire Service Kit is not a permanent flat tire

repair. Have the tire inspected and repaired or

replaced after using the Tire Service Kit. Do not

exceed 50 mph (80 km/h) until the tire is

repaired or replaced. Failure to follow this

warning can result in injuries that are serious or

fatal to you, your passengers, and others around

you. Have the tire checked as soon as possible

at an authorized dealer.

7

21_RUP_OM_EN_USC_t.book  Page 301

Detailed Information for 2021 Chrysler Pacifica Owner's Manual

Lists of information found in 2021 Chrysler Pacifica Owner's Manual - Page 303

  • 1.8 Bar) pressure within 15 minutes: NOTE: If the tire becomes overinflated, push the Deflation Button to reduce the tire pressure to the recom - mended inflation pressure before continuing.
  • 1. Push the Power Button to turn the Tire Service Kit off.
  • 2. Remove the speed limit label from the Tire Service Kit and place sticker on the steering wheel.
  • 3. Immediately disconnect the Sealant Hose from the valve stem, reinstall the cap on the fitting at the end of the hose, and place the Tire Service Kit in the vehicle storage location.
  • 1. Uncoil the Sealant Hose, and then remove the cap from the fitting at the end of the hose.
  • 2. Place the Tire Service Kit flat on the ground next to the deflated tire.
  • 3. Remove the cap from the valve stem, and then screw the fitting at the end of the Sealant Hose onto the valve stem.
  • 4. Uncoil the Power Plug and insert the plug into the vehicle's 12 Volt power outlet.
  • 5. Uncoil the Hose and screw the fitting at the end of the hose onto the valve stem.
  • 6. Turn the Mode Select Knob and turn to the Air Mode position.
  • 7.Check the pressure in the tire by reading the Pressure Gauge.
  • 1.3 Bar): The tire is too badly damaged.
