302

IN CASE OF EMERGENCY



If the tire pressure is 19 psi (1.3 Bar) or higher:

1. Push the Power Button to turn on

Tire Service Kit and inflate the tire to

the cold tire inflation pressure found

on the tire and loading information

label located in the driver-side door opening.

NOTE:

If the tire becomes overinflated, push the Deflation

Button to reduce the tire pressure to the recom

-

mended inflation pressure before continuing.
2. Disconnect the Tire Service Kit from the valve

stem, reinstall the cap on the valve stem and

unplug from 12 Volt outlet.

3. Place the Tire Service Kit in its proper storage

area in the vehicle.

4. Have the tire inspected and repaired or

replaced at the earliest opportunity at an

authorized dealer or tire service center.

5. Remove the Speed Limit sticker from the

steering wheel after the tire has been repaired.

6. Replace the Sealant Bottle at an authorized

dealer as soon as possible.

NOTE:

When having the tire serviced, advise the autho

-

rized dealer or service center that the tire has been

sealed using the Tire Service Kit.

Sealant Bottle Replacement:
1. Unwrap the power cord.
2. Unwrap the hose.

Hose Location

3. Remove the bottle cover.

Remove The Bottle Cover

4. Rotate the bottle up beyond vertical to release.

Rotate The Bottle Up

5. Pull the bottle away from the Compressor.

Remove The Bottle

NOTE:

For sealant bottle installation, follow these

steps reverse order.

Replacement sealant bottles are available at

authorized service centers.
