396

IN CASE OF EMERGENCY



T

O

 S

TOW

 T

HE

 F

LAT

 O

R

 S

PARE

1. Turn the wheel so that the valve stem is

facing upward and toward the rear of the

vehicle for convenience in checking the

spare tire inflation. Slide the wheel retainer

through the center of the wheel.

2. Lift the spare tire with one hand to give

clearance to tilt the retainer at the end of

the cable and position it properly across the

wheel opening.

Reinstalling The Retainer

3. Attach the lug wrench to the extension

tubes with the curved angle facing away

from the vehicle. Insert the extension tubes

through the access hole between the lower

tailgate and the top of the fascia/bumper

and into the winch mechanism tube.

Reinstalling The Flat Or Spare Tire

4. Rotate the lug wrench handle clockwise

until the wheel is drawn into place against

the underside of the vehicle. Continue to

rotate until you feel the winch mechanism

slip, or click three or four times. It cannot be

overtightened. Push against the tire several

times to ensure it is firmly in place.

Rotating The Lug Wrench Handle

NOTE:

The winch mechanism is designed for use with

the extension tube only. Use of an air wrench or

other power tools is not recommended and can

damage the winch.

WARNING!

A loose tire or jack thrown forward in a

collision or hard stop could endanger the

occupants of the vehicle. Always stow the jack

parts and the spare tire in the places

provided. Have the deflated (flat) tire repaired

or replaced immediately.

21_JT_OM_EN_USC_t.book  Page 396

Detailed Information for 2021 Jeep Gladiator Owner's Manual

Lists of information found in 2021 Jeep Gladiator Owner's Manual - Page 398

  • 1. Turn the wheel so that the valve stem is facing upward and toward the rear of the vehicle for convenience in checking the spare tire inflation.
  • 2. Lift the spare tire with one hand to give clearance to tilt the retainer at the end of the cable and position it properly across the wheel opening.
  • 3. Attach the lug wrench to the extension tubes with the curved angle facing away from the vehicle.
  • 4. Rotate the lug wrench handle clockwise until the wheel is drawn into place against the underside of the vehicle.
