SERVICING AND MAINTENANCE

447

F85

–

10 Amp Red

PM SENSOR*

F86

–

–

Spare*

F87

–

10 Amp Red

SUPPLY/PURGING PMP*

F88

20 Amp Blue

–

NOx SENSOR #1/#2*

F89

–

10 Amp Red

Steering Column Control Module (SCCM)/Cruise Control

(CRUISE CTL)/Digital TV (DTV)/Airbag Disable Lamp

F90

20 Amp Blue

–

TRAILER TOW PARK LMP*

F91

–

20 Amp Yellow

Horn

F92

40 Amp Green

–

HD ACCY #2*

F93

40 Amp Green

–

HD ACCY #1*

F94

–

10 Amp Red

Tire Pressure Monitor (TPM)/RF Hub system (CORAX)

F95

–

–

Spare*

F96

–

10 Amp Red

PWR MIRROR SW

F97

–

20 Amp Yellow

RADIO/TBM

F98

–

10 Amp Red

SW BANK-HD ELEC/OFF ROAD

F99

–

–

Spare*

F100

30 Amp Pink

–

ESC-ECU & VALVES

F101

30 Amp Pink

–

Drivetrain Control Module (DTCM)

F102

–

15 Amp Blue

DUAL USB PORT

Cavity

Cartridge Fuse

Micro Fuse

Description

* If Equipped
