HST Pedal Sensor: for HST

The HST pedal sensor is located on the right of the

HST pedal. When the HST pedal is operated, signals are

sent to the ECU.

9Y1210824ELM0076US0

Main ECU (Electrical Control Unit)

The main ECU is located inside of steering cover.

9Y1210824ELM0077US0

Engine ECU (Electrical Control Unit)

The engine ECU is located under the floor seat.

9Y1210824ELM0078US0

(1) HST Pedal Sensor

(1) Main ECU

(1) Engine ECU
