GENERAL

L3560, L4060, L4760, L5060, L5460, L6060, WSM

G-31

Changing Transmission Fluid / Replacing Hydraulic Oil Filter



Cleaning Magnetic Filter

 CAUTION

• Be sure to stop the engine before changing the oil filter

cartridge.

• Allow engine to cool down sufficiently, oil can be hot and

can burn.

1. Remove the drain plugs at the bottom of the transmission case

and drain the oil completely into the oil pan.

2. After draining reinstall the drain plugs.

3. Remove the oil filter.

4. Wipe off metal filings from the magnetic filter with a clean rag.

5. Put a film of clean transmission oil on the rubber seal of the new

filter.

6. Quickly tighten the filter until it contacts the mounting surface,

then tighten it by hand an additional 1/2 turn only.

7. Fill with the new KUBOTA SUPER UDT fluid up to the upper

notch on the dipstick. (Refer to "4. LUBRICANTS, FUEL AND

COOLANT" on page G-9.)

8. After running the engine for a few minutes, stop the engine and

check the oil level again, add oil to the prescribed level.

9. Make sure that the transmission fluid doesn't leak past the seal

on the filter.

IMPORTANT

• To prevent serious damage to the hydraulic system, use

only a KUBOTA genuine filter.

• Do not operate the tractor immediately after changing the

transmission fluid.
Run the engine at medium speed for a few minutes to
prevent damage to the transmission.

9Y1210824GEG0056US0

Transmission oil

capacity

L3560

42 L

11.1 U.S.gals

9.2 Imp.gals

L4060

L4760

43 L

11.4 U.S.gals

9.5 Imp.gals

L5060

L5460

L6060

45 L

11.9 U.S.gals

9.9 Imp.gals

(1) Drain Plug

(2) Hydraulic Oil Filter

(3) Magnetic Filter (Wipe Off Metal

Filings)

(4) Gauge

(5) Oil Inlet

[A] GST / Manual Transmission
[B] HST
A: Oil level is acceptable within this

range.
