ENGINE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

1-S25

Draining the Transmission Fluid

 CAUTION

• Allow the engine to cool down sufficiently, oil can be hot

and burn.

1. Place oil pans underneath the transmission case.

2. Remove the drain plugs (1).

3. Drain the transmission fluid completely.

4. Reinstall the drain plugs (1).

(When refilling)

• Fill  up  from  filling  port  after  removing  the  filling  plug  (2)  until

reaching the upper notch on the dipstick (3).

• After running the engine for a few minutes, stop it and check the

oil level again, add the fluid to prescribed level if it is not correct

level.

IMPORTANT

• Use only KUBOTA SUPER UDT fluid. Use of other oils may

damage the transmission or hydraulic system. (Refer to "4.
LUBRICANTS, FUEL AND COOLANT" on page G-9.)

• Do not mix different brands of fluid together.

9Y1210824CLS0005US0

Transmission fluid

capacity

L3560

42 L

11.1 U.S.gals

9.24 Imp.gals

L4060

L4760

43 L

11.4 U.S.gals

9.5 Imp.gals

L5060

L5460

L6060

45 L

11.9 U.S.gals

9.90 Imp.gals

(1) Drain Plugs

(2) Filling Plug

(3) Dipstick

[A] Manual Transmission / GST
[B] HST
A: Oil level is acceptable within this

range.

KiSC issued 03, 2016 A
