ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-M30

(Continued)

9Y1210824ELM0048US0

Display

Model

Message

Description

A

HST

"L", "H", "M" or "N"

Display the position of the range gear shift that was

selected with the range gear shift lever.

GST

"F1" to "F12" or "R1"

to "R12" or "N"

"F" is displayed when forward operation is selected with

the shuttle lever.

"R" is displayed when reverse operation is selected.

Displays the number of the gear shift ratios that was

selected with the main gear shift lever.

"N" is displayed when the lever is in the neutral position.

Manual

Transmission

"F", "R" or "N"

"F" is displayed when forward operation is selected with

the shuttle lever.

"R" is displayed when reverse operation is selected.

"N" is displayed when the lever is in the neutral position.

All Model

Appears when the time for an engine oil change has

come.

Change the engine oil with fresh one.

Stays displayed for 3 seconds or so after the engine

has got started. Buckle up the seat belt.

Stays displayed while the cooling water temperature is

too low and the glow plug is being activated. Wait until

this symbol disappears and get the engine started.
Appears when the fuel has become less than 6 L (1.5

U.S.gals) or so. Refuel as soon as possible. If the fuel

tank becomes empty, air will enter the fuel system,

thereby requiring a bleeding.

0.1 to 34

Displays the travel speed. (The actual speed is different

from the displayed one if the tires slip in towing or other

jobs.)

0:00 to 11:59

Displays the clock. When (― ― : ― ―) is displayed,

make the time setting.

Nothing is displayed if this is disabled.

B

All Model

Messages on the

right side on the

lower side of the

IntelliPanel™

The hour meter, trip meter, fuel consumption, PTO rpm,

HST setting, PM volume status, time elapsed since the

previous engine oil change and other data can be

displayed.
